Suurin kaasun paine: 25Bar
Collimating Focal length：75mm / 100mm
Focusing Focal Length : 100mm / 125mm / 150mm
Horizontal Adjustment Range : ±1.5mm
Vertical Adjustment Range : ±5mm
Effective Aperture : 20mm
Gross weight : 2.8kg
Applicable power l ：≤1000w
Can be equipped with Qcs connector.Can be used for lasers below 100ow. Can be used for general purpose lasers such as IPG, SPI,Rofin, Raycus,MAX, JPT,CAS, etc.
